Washing Thickener

Washing Thickener
Product Introduction
Washing thickener for solid-liquid separation of gold leaching liquid
Capacity
10-250t/d
Product Features
1, Countercurrent washing, large capacity and high washing efficiency
2, Small area taken
3, Stable production and convenient operation

Advantages

Washing thickener

  • The continuous ore discharge method can reduce the multiple cycle of liquid gold, while extending the time of pulp staying in the washing thickener to improve the leaching rate;

  • Countercurrent washing, large capacity and high washing efficiency

  • Small area taken, reasonable structure and low cost of operation and maintenance


Work Principle

Ore pulps enter into tank and then free settle in rake zone where ore pulps are compressed by scraper and moved by rake toward the discharge opening located in tank center through which ore pulps are discharged to next tank. Via distributing box, clear water enters the lowest layer to scrub minerals. After that, overflow of the lowest layer comes back to distributing box to scrub minerals of upper layer. Overflow of first layer is discharged through overflow dam; minerals----which are scrubbed for three times----are discharged from bottom end.

It is mainly used to countercurrent scrubbing of gold cyaniding process. Three layers washing thickener is also applicable to scrubbing and dehydration in wet metallurgy, light industry and chemical industry.

Product Structure

Double-deck Scrubbing Thickener

Technical Parameters

Spec.

Diameter
(m)

Depth of Center Tank (m)

Subsidence Area (m2)

Revolution of Harrow Frame (r/min)

Capacity
(t/d)

Motor Model

Motor
Power
(kW)

Weight
(kg)

Remarks

2NZS6

6

5.34

56.5

0.25

≤ 50

Y112M-6

2.2

13360

Excluding the pond weight

2NZS7

7

5.41

77

≤ 56

14200

2NZS8

8

6.08

100.7

0.28

≤ 68

Y132M1-6

4

50449

Including the pond weight

2NZS9

9

5.91

127.3

≤ 88

54628

2NZS12

12

6.87

226

0.2

≤ 160

Y132M2-6

5.5

40400

Excluding the pond weight

2NZS15

15

6.95

353.3

0.15

≤ 250

51470
